Terrestrial input 1
Frequency range 5..862 MHz
Terrestrial tap - 6 dB
Tap to tap isolation >= 35 dB
CSS technology a²CSS2
Satellite inputs 8
Satellite freq. range L 950..2200 MHz
Satellite trunk L - 0,5 .. - 1,5 dB
Sat input level range L 60 .. 90 dBmV
Satellite freq. range W 290 .. 3400 MHz
Satellite trunk W - 0,5 .. - 2,5 dB
Sat input level range W 70 .. 90 dBmV
Tap to tap isolation >= 26 dB
No of legacy/CSS taps 2
Number of UBs 2 x 16
Output level 90 dBmV
Max. receiver load @14V 270 mA
LNB supply external
Dimensions [mm³] 211 x 144 x 34
Screening/EMC CE, Class A
